Self‑propelled Super Concrete Vibrating Screed-奥力德工程装备

Gear‑box self‑propelled transmission: Automatic forward‑backward walking, no manual pushing, greatly reduce labor intensity.
Multiple power options: Gasoline or diesel engine, 7.5HP /9HP, strong power for outdoor road construction sites.
Double‑layer reinforced magnesium‑aluminum screed plate: High rigidity, anti‑deformation for uniform vibration transmission.
Customizable multiple sizes: Screed length 3.0‑7.5m optional, weight changes according to actual plate size, max paving depth 20cm.
High‑efficiency construction: Working speed 30‑60m/h, finish paving, compaction, slurry lifting and leveling in one pass for roads and squares.

The self‑propelled super vibrating screed changes traditional manual screed working mode. Equipped with gear‑box transmission for self‑walking, no heavy manual pulling. Support gasoline or diesel engine, 7.5HP /9HP power options. The screed plate is double‑layer magnesium‑aluminum alloy with reinforcing ribs, anti‑twist and durable for even vibration. Multiple screed lengths 3.0m‑7.6m for option, max paving depth reaches 20cm, working speed 30‑60m/h. Widely applied for country roads, squares and factory concrete floor projects.

Main Configuration

‑ Drive Mode: Gear‑box self‑propelled transmission

‑ Power Type: Gasoline / Diesel,7.5HP /9HP

‑ Vibrating Plate: Double‑layer magnesium‑aluminum alloy with reinforcing ribs

‑ Paving Depth:20cm

‑ Working Speed:30‑60m/h

‑ Optional Screed Length:3-7.5

‑ Machine Weight:81‑108kg (varies by plate length)

‑ Remark: Screed size customizable, weight depends on actual dimension

Advantages

✅ Self‑propelled gear‑box drive, free from heavy manual pushing

✅ Gasoline & diesel power choices, strong performance for outdoor sites

✅ Reinforced double‑layer Mg‑Al plate, anti‑deformation for long service life

✅ Multiple customizable lengths fit different road & square width

✅ One‑step paving, compaction & leveling, high construction efficiency
